Revit family for a wall-mounted hand dryer
Wall-mounted hand dryer, wall hosted, 120 V
A sample family
A sample family from this generator. Planning grade: verify before construction documents. Free to use in your projects.
Opens in Revit 2024 and later.
| What you gave us | A spec sheet with the electrical table and a mounting drawing, one photo |
|---|---|
| Levels offered | Standard, Detailed |
| What the family carries | Wall based at the mounting height from the drawing. An electrical connector at the sheet's voltage and amps, clearances from the wall |
| Credits | 2 or 3 |
Connectors and types are only built from what the sheet says. If the electrical table or the rough-in is missing, we ask for it before the build rather than guess.
